15.30 Converting DINT to REAL
DINT_TO_REAL(_E)
These functions convert DINT type data to REAL type data.
Setting data
■Descriptions, types, and data types
Processing details
■Operation processing
• These functions convert the DINT type data input to (s) to REAL type data and output from (d).
• A value input to (s) is the DINT type data value.
• The number of significant figures of the REAL type data is approximately 7 since the data is processed in 32-bit single
precision.
• The converted data includes an error (rounding error) if an integer value is outside the range of -16777216 to 16777215.
■Operation result
1. Function without EN/ENO
The operation processing is executed. The operation output value is output from (d).
2. Function with EN/ENO
The following table lists the execution conditions and operation results.
*1 When FALSE is output from ENO, data output from (d) is undefined. In that case, modify a program so that the data output from (d) is
not used.
Operation error
There is no operation error.
Ladder diagram Structured text
[Without EN/ENO] [With EN/ENO] [Without EN/ENO]
d:=DINT_TO_REAL(s);
[With EN/ENO]
d:=DINT_TO_REAL_E(EN,ENO,s);
Argument Description Type Data type
EN Execution condition (TRUE: Execution, FALSE: Stop) Input variable BOOL
s Input Input variable DINT
ENO Output status (TRUE: Normal, FALSE: Abnormal) Output variable BOOL
d Output Output variable REAL
Execution condition Operation result
EN ENO (d)
TRUE (Executes operation) TRUE Operation output value
FALSE (Stops operation) FALSE
*1
Indefinite value
sd
EN ENO
ds
DINT
16543521
REAL
16543521.0
(s)
(d)
