15 TYPE CONVERSION FUNCTIONS
15.29 Converting DINT to BCD
■Operation result
1. Function without EN/ENO
The following table lists the operation results.
2. Function with EN/ENO
The following table lists the execution conditions and operation results.
*1 When FALSE is output from ENO, data output from (d) is undefined. In that case, modify a program so that the data output from (d) is
not used.
Operation error
• When (d) is WORD
• When (d) is DWORD
Operation result (d)
No operation error occurred Operation output value
An operation error occurred Indefinite value
Execution condition Operation result
EN ENO (d)
TRUE (Executes operation) TRUE (Operation error did not occur) Operation output value
FALSE (Operation error occurred)
*1
Indefinite value
FALSE (Stops operation) FALSE
*1
Indefinite value
Error code
(SD0/SD8067)
Description
3401 The 32-bit signed binary data in the device specified by (s) is out of the valid range (-32768 to 32767).
Data in the device specified by (s) is out of the valid range (0 to 9999).
Error code
(SD0/SD8067)
Description
3401 Data in the device specified by (s) is out of the valid range (0 to 99999999).
