Mitsubishi MELSEC iQ-F FX5 series User Manual

6 BASIC INSTRUCTIONS
6.2 Arithmetic Operation Instructions
187
6
Dividing 32-bit binary data
D/(P)(_U) instruction and DDIV(P)(_U) instruction can be used for division of 32-bit binary data.
D/(P)(_U)
These instructions divide the 32-bit binary data in the device specified by (s1) by the 32-bit binary data in the device specified
by (s2), and store the result in the device specified by (d).
Setting data
■Descriptions, ranges, and data types
■Applicable devices
Processing details
• These instructions divide the 32-bit binary data in the device specified by (s1) by the 32-bit binary data in the device
specified by (s2), and store the division result in the device specified by (d).
• For the division result of word device, 64-bit binary is used to store the quotient and remainder. For bit device, 32-bit binary
is used to store quotient only.
Operation error
Ladder diagram Structured text
Not supported
Operand Description Range Data type Data type (label)
(s1) D/(P) Dividend data or the head device where the
data to be divided by another is stored
-2147483648 to +2147483647 32-bit signed binary ANY32
D/(P)_U 0 to 4294967295 32-bit unsigned binary ANY32_U
(s2) D/(P) Divisor data or the head device where the data
by which another is to be divided is stored
-2147483648 to +2147483647 32-bit signed binary ANY32
D/(P)_U 0 to 4294967295 32-bit unsigned binary ANY32_U
(d) D/(P) Head device for storing the operation result  64-bit signed binary ANY32_ARRAY
(Number of elements:
2)
D/(P)_U 64-bit unsigned binary
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s1)       
(s2)       
(d)          
Error code
(SD0/SD8067)
Description
2820 The range of the device specified by (d) exceeds the range of said device.
3400 0 is specified for (s2) value.
3403 Signed operation is performed and the operation result exceeds 2147483647.
(s1) (s2) (d)
567890 (BIN)
123456 (BIN) 4 (BIN)
÷
(d)
(d)+1
b0
··· ···
b31 b16 b15
(s2)
(s2)+1
b0
··· ···
b31 b16 b15
(s1)
(s1)+1
b0
··· ···
b31 b16 b15
74066 (BIN)
(d)+2
(d)+3
b0
··· ···
b31 b16 b15
