6 BASIC INSTRUCTIONS
6.2 Arithmetic Operation Instructions
DDIV(P)(_U)
These instructions divide the 32-bit binary data in the device specified by (s1) by the 32-bit binary data in the device specified
by (s2), and store the result in the device specified by (d).
Setting data
■Descriptions, ranges, and data types
■Applicable devices
Processing details
• These instructions divide the 32-bit binary data in the device specified by (s1) by the 32-bit binary data in the device
specified by (s2), and store the division result in the device specified by (d).
■Related flag
Precautions
■Operation result
• The most significant bit of the quotient and remainder indicates the sign (positive: 0, negative: 1), respectively.
• The quotient is negative when either (s1) or (s2) is negative. The remainder is negative when the (s1) is negative.
■Device specified by (d)
• The remainder is not obtained when a bit device is specified with nibble specification.
Ladder diagram Structured text
ENO:=DDIV(EN,s1,s2,d);
ENO:=DDIVP(EN,s1,s2,d);
ENO:=DDIV_U(EN,s1,s2,d);
ENO:=DDIVP_U(EN,s1,s2,d);
Operand Description Range Data type Data type (label)
(s1) DDIV(P) Dividend data or the head device where the
data to be divided by another is stored
-2147483648 to +2147483647 32-bit signed binary ANY32_S
DDIV(P)_U 0 to 4294967295 32-bit unsigned binary ANY32_U
(s2) DDIV(P) Divisor data or the head device where the data
by which another is to be divided is stored
-2147483648 to +2147483647 32-bit signed binary ANY32_S
DDIV(P)_U 0 to 4294967295 32-bit unsigned binary ANY32_U
(d) DDIV(P) Head device for storing the operation result  64-bit signed binary ANY32_S_ARRAY
(Number of elements:
2)
DDIV(P)_U 64-bit unsigned binary ANY32_U_ARRAY
(Number of elements:
2)
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s1)       
(s2)       
(d)          
Device Name Description
SM700 Carry When the operation result of the signed operation exceeds 32767, the carry flag is turned ON.
SM8304 Zero When the operation result is 0, the zero flag is turned ON.
SM8306 Carry When the operation result of the signed operation exceeds 32767, the carry flag is turned ON.
(s1) (s2) (d)
567890 (BIN)
123456 (BIN) 4 (BIN)
÷
(d)
(d)+1
b0
··· ···
b31 b16 b15
(s2)
(s2)+1
b0
··· ···
b31 b16 b15
(s1)
(s1)+1
b0
··· ···
b31 b16 b15
74066 (BIN)
(d)+2
(d)+3
b0
··· ···
b31 b16 b15
