Mitsubishi MELSEC iQ-F FX5 series User Manual

178
6 BASIC INSTRUCTIONS
6.2 Arithmetic Operation Instructions
MUL(P)(_U)
These instructions multiply the 16-bit binary data in the device specified by (s1) by the 16-bit binary data in the device
specified by (s2), and store the result in the device specified by (d).
*1 The MUL instruction is not supported by the ST language. Use MUL of the standard function.
Page 779 MUL(_E)
Setting data
■Descriptions, ranges, and data types
■Applicable devices
Processing details
• These instructions multiply the 16-bit binary data in the device specified by (s1) by the 16-bit binary data in the device
specified by (s2), and store the multiplication result in the device specified by (d).
Ladder diagram Structured text
*1
ENO:=MULP(EN,s1,s2,d); ENO:=MUL_U(EN,s1,s2,d);
ENO:=MULP_U(EN,s1,s2,d);
Operand Description Range Data type Data type (label)
(s1) MUL(P) Multiplicand data or the device where the data
to be multiplied by another is stored
-32768 to +32767 16-bit signed binary ANY16_S
MUL(P)_U 0 to 65535 16-bit unsigned binary ANY16_U
(s2) MUL(P) Multiplier data or the device where the data by
which another is to be multiplied is stored
-32768 to +32767 16-bit signed binary ANY16_S
MUL(P)_U 0 to 65535 16-bit unsigned binary ANY16_U
(d) MUL(P) Head device for storing the operation result  32-bit signed binary ANY32_S
MUL(P)_U 32-bit unsigned binary ANY32_U
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s1)       
(s2)       
(d)       
(s1) (s2) (d)
b15 b0
5678 (BIN)
(s1) (s2)
1234 (BIN) 7006652 (BIN)
×
···
b15 b0
···
(d)
(d)+1
b0
··· ···
b31 b16 b15
