580
7 APPLICATION INSTRUCTION
7.19 Clock instruction
• These instructions occupy seven points of device starting from device number specified by (d). Make sure that these
devices are not used by other machine controls.
SD8018 Binary clock data (year) The year data in the clock data is stored as a four-digit binary code.
SD8019 Binary clock data (day of the week) The day-of-a-week data in the clock data (0: Sunday, 1: Monday, ..., 6: Saturday) is stored as a binary code.
Error code
(SD0/SD8067)
Description
2820 The device range specified by (d) exceeds the corresponding device range.
Device Name Description
To Next Page
