7 APPLICATION INSTRUCTION

7.7 Real Number Instruction

Operation error

Error code

(SD0/SD8067)

Description

2820 The device areas specified by (s) exceed the corresponding device range.

The device areas specified by (d) exceed the corresponding device range.

3402 The block data in the device areas specified by (s) includes a value other than single-precision real number.
