6 BASIC INSTRUCTIONS
6.2 Arithmetic Operation Instructions
-(P)(_U) [using three operands]
These instructions subtract the 16-bit binary data in the device specified by (s1) and the 16-bit binary data in the device
specified by (s2), and store the result in the device specified by (d).
Setting data
■Descriptions, ranges, and data types
■Applicable devices
Processing details
• These instructions subtract the 16-bit binary data in the device specified by (s1) and the 16-bit binary data in the device
specified by (s2), and store the subtraction result in the device specified by (d).
• When underflow or overflow occurs in the operation result, the following processing is executed. In this case, the carry flag
(SM700, SM8022) does not turn ON.
Operation error
There is no operation error.
Ladder diagram Structured text
ENO:=MINUS(EN,s1,s2,d);
ENO:=MINUSP(EN,s1,s2,d);
ENO:=MINUS_U(EN,s1,s2,d);
ENO:=MINUSP_U(EN,s1,s2,d);
Operand Description Range Data type Data type (label)
(s1) -(P) Minuend data or the device where the data
from which another is to be subtracted is
stored
-32768 to +32767 16-bit signed binary ANY16_S
-(P)_U 0 to 65535 16-bit unsigned binary ANY16_U
(s2) -(P) Subtrahend data or the device where the data
to be subtracted from another is stored
-32768 to +32767 16-bit signed binary ANY16_S
-(P)_U 0 to 65535 16-bit unsigned binary ANY16_U
(d) -(P) Device for storing the operation result  16-bit signed binary ANY16_S
-(P)_U  16-bit unsigned binary ANY16_U
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s1)       
(s2)       
(d)       
(s1) (s2) (d)
b15 b0
5678 (BIN)
(s1) (s2) (d)
1234 (BIN) 4444 (BIN)
-
···
b15 b0
···
b15 b0
···
-
-
-
- →
→
→
K0 K65535 K1
(0000H) (FFFFH) (0001H)
→
K32767 K-2 K-32767
K0 K1 K65535
K-32768 K2 K32766
(0000H) (0001H) (FFFFH)
(8000H) (0002H) (7FFEH)
(FFFEH) (8001H)(7FFFH)
In case of -(P)
Because the highest bit is 1, the value is negative.
In case of -(P)(_U)
Because the highest bit is 0, the value is positive.
