6 BASIC INSTRUCTIONS

6.2 Arithmetic Operation Instructions

Precautions

■Operation result

• The most significant bit of the quotient and remainder indicates the sign (positive: 0, negative: 1), respectively.

• The quotient is negative when either (s1) or (s2) is negative. The remainder is negative when the (s1) is negative.

■Device specified by (d)

• The remainder is not obtained when a bit device is specified with nibble specification.

Operation error

Error code

(SD0/SD8067)

Description

2820 The range of the device specified by (d) exceeds the range of said device.

3400 0 is specified for (s2) value.

3403 The data type of the data setting is signed data and the operation result exceeds 32767.
