Mitsubishi MELSEC iQ-F FX5 series User Manual

6 BASIC INSTRUCTIONS
6.2 Arithmetic Operation Instructions
185
6
DMUL(P)(_U)
These instructions multiply the 32-bit binary data in the device specified by (s1) and the 32-bit binary data in the device
specified by (s2), and store the result in the device specified by (d).
Setting data
■Descriptions, ranges, and data types
■Applicable devices
Processing details
• These instructions multiply the 32-bit binary data in the device specified by (s1) by the 32-bit binary data in the device
specified by (s2), and store the multiplication result in the device specified by (d).
• When nibble is specified ranging from K1 to K8 for (d), the result is obtained only for the lower-order 32 bits, and is not
obtained for the higher-order 32 bits. Transfer the data to word devices once, then execute the operation.
■Related flag
Ladder diagram Structured text
ENO:=DMUL(EN,s1,s2,d);
ENO:=DMULP(EN,s1,s2,d);
ENO:=DMUL_U(EN,s1,s2,d);
ENO:=DMULP_U(EN,s1,s2,d);
Operand Description Range Data type Data type (label)
(s1) DMUL(P) Multiplicand data or the head device where the
data to be multiplied by another is stored
-2147483648 to +2147483647 32-bit signed binary ANY32_S
DMUL(P)_U 0 to 4294967295 32-bit unsigned binary ANY32_U
(s2) DMUL(P) Multiplier data or the head device where the
data by which another is to be multiplied is
stored
-2147483648 to +2147483647 32-bit signed binary ANY32_S
DMUL(P)_U 0 to 4294967295 32-bit unsigned binary ANY32_U
(d) DMUL(P) Head device for storing the operation result  64-bit signed binary ANY32_S_ARRAY
(Number of elements:
2)
DMUL(P)_U 64-bit unsigned binary ANY32_U_ARRAY
(Number of elements:
2)
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s1)       
(s2)       
(d)          
Device Name Description
SM8304 Zero When the operation result is 0, the zero flag is turned ON.
(s1) (s2) (d)
b0
567890 (BIN)
(s1)
123456 (BIN) 70109427840 (BIN)
×
··· ···
(s1)+1
(s2)
(s2)+1
(d)+2
(d)+3
b31 b16 b15
b0
··· ···
b31 b16 b15
b32
··· ···
b63 b48 b47
(d)
(d)+1
b0
··· ···
b31 b16 b15
DMUL D50 K150 D100
(D51,D50) (D103,D102,D101,D100)
K100 × K150 → K15000
DMOV D100 K8Y0
D100 → Y17 to Y0
DMOV D102 K8Y40
D102 → Y57 to Y40
(s2) (d)(s1)
Command
input
D101 → Output to Y37 to Y20
D103 → Output to Y77 to Y60
