6 BASIC INSTRUCTIONS
6.3 Logical Operation Instructions
WXOR(P) [using three operands]
These instructions exclusive OR each bit of 16-bit binary data from the device specified by (s1) and each bit of 16-bit binary
data from device specified by (s2), and store the results in the device specified by (d).
■Descriptions, ranges, and data types
■Applicable devices
• These instructions exclusive OR each bit of 16-bit binary data from the device specified by (s1) and each bit of 16-bit binary
data from device specified by (s2), and store the results in the device specified by (d).
• Bit devices subsequent to number of points by nibble specification are calculated as 0.
There is no operation error.
Ladder diagram Structured text
ENO:=WXOR(EN,s1,s2,d);
ENO:=WXORP(EN,s1,s2,d);
Operand Description Range Data type Data type (label)
(s1) Data for exclusive OR or head device where data is stored -32768 to +32767 16-bit signed binary ANY16
(s2) Data for exclusive OR or head device where data is stored -32768 to +32767 16-bit signed binary ANY16
(d) Head device for storing exclusive OR results 16-bit signed binary ANY16
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s1)
(s2)
(d)
(s1)
(d)
(s2)
···
···
···
···
···
···
b15
b15
b15
b8
b8
b8
b7
b7
b7 b0
b0
b0
XOR
000 10111111 10000
010 01101001 10101
010 11010110 00101
