7 APPLICATION INSTRUCTION

7.4 Structuring instruction

343

Operation error

Error code

(SD0/SD8067)

Description

3340 The branch pointer number outside two nesting levels or more is specified.

3342 The BREAK(P) instructions are used other than between the FOR and NEXT instructions.

3380 The destination pointer specified by (P) does not exist.

A pointer in other program file is specified in (P).
