7 APPLICATION INSTRUCTION

7.7 Real Number Instruction

417

Precautions

The same device number can be specified for (s1), (s2), and (d). In this case, note that the subtraction result changes in every

operation cycle when the continuous operation type instruction (DESUB) is used.

Operation error

Error code

(SD0/SD8067)

Description

3402 The specified device value is denormalized number, NaN (not a number), or .
