7 APPLICATION INSTRUCTION

7.10 Data control instruction

477

Ex.

When (s1) is 10 and (s3) is -32768: Output value = -32768-10 = 8000H-000AH = 7FFFH = 32758

• When the output value to be stored in the device specified by (d) is a 16-bit unsigned binary value and the operation result

exceeds the range of 0 to 65535, the output value is calculated as follows.

Ex.

When (s1) is 100 and (s3) is 50: Output value = 50-100 = 0032H-0064H = FFCEH = 65486

Operation error

Error code

(SD0/SD8067)

Description

3405 The lower limit value specified by (s1) is greater than the upper limit value specified by (s2).
