7 APPLICATION INSTRUCTION

7.11 Special timer instruction

497

Precautions

• When the command contact turns from on to off, the current value (d)+1 of the pressing and holding time is cleared, and the

teaching time (d) will not change any more.

• Two devices are occupied from a device specified as the teaching time (d). Make sure that such devices are not used in

other controls for the machine.

Operation error

Error code

(SD0/SD8067)

Description

2820 The device range specified by (d) exceeds the corresponding device range.

3405 The value specified by (s) is outside the following range.

0 to 2
