Mitsubishi MELSEC iQ-F FX5 series User Manual

2 CPU MODULE INSTRUCTION
2.2 Basic instruction
51
2
■Adding/subtracting 16-bit binary block data
■Adding/subtracting 32-bit binary block data
■Incrementing/decrementing 16-bit binary data
■Incrementing/decrementing 32-bit binary data
Instruction symbol Description Reference
BK+ Adds the 16-bit binary bit data in the device area ((n) points) from (s1) and the data or constants in
the device area ((n) points) from (s2) at once, and stores the result in the device area ((n) points)
from (d).
Page 202
BK+P
BK+_U
BK+P_U
BK- Subtracts the 16-bit binary bit data in the device area ((n) points) from (s1) and the data or
constants in the device area ((n) points) from (s2) at once, and stores the result in the device area
((n) points) from (d).
Page 204
BK-P
BK-_U
BK-P_U
Instruction symbol Description Reference
DBK+ Adds the 32-bit binary bit data in the device area ((n) points) from (s1) and the 32-bit data or
constants in the device area ((n) points) from (s2), and stores the result in the device area specified
by (d) and later.
Page 206
DBK+P
DBK+_U
DBK+P_U
DBK- Subtracts the 32-bit binary bit data in the device area ((n) points) from (s1) and the 32-bit data or
constants in the device area ((n) points) from (s2) and later, and stores the result in the device area
specified by (d) and later.
Page 209
DBK-P
DBK-_U
DBK-P_U
Instruction symbol Description Reference
INC (d) + 1  (d) Page 211
INCP
INC_U
INCP_U
DEC (d) - 1  (d) Page 212
DECP
DEC_U
DECP_U
Instruction symbol Description Reference
DINC [(d)+1, (d)] + 1  [(d)+1, (d)] Page 213
DINCP
DINC_U
DINCP_U
DDEC [(d)+1, (d)] -1  [(d)+1, (d)] Page 214
DDECP
DDEC_U
DDECP_U
