528
7 APPLICATION INSTRUCTION
7.14 Pulse related instruction
Error code
(SD0/SD8067)
Description
Axis 1 Axis 2 Axis 3 Axis 4
SD5510 SD5550 SD5590 SD5630
1810 The axis number specified by (d) is used by another instruction.
2820 The value specified by (s) is outside the following range.
0 to 65535
The value specified by (n) is outside the following range.
0 to 65535
The value specified by (d) is outside the following range.
0 to 3
3600 The axis number specified by (d) is not set by parameters.
A function which is set to be not used by parameters (such as interrupt input signal 1 and zero return
relations) is used.
3631 3632 3633 3634 The numbers of pulses (by the pulses conversion) of the positioning address specified by (n) exceed the 32-
bit range.
3641 3642 3643 3644 The numbers of pulses (by the pulses conversion) of the command speed specified by (s) exceed the 32-bit
range.
3651 3652 3653 3654 The operation decelerates and stops by the forward limit or reverse limit during the pulse output or at the
activating of the positioning.
3661 3662 3663 3664 The operation decelerates and stops by the pulse output stop command or special relay whose all outputs
are disabled during the pulse output or at the activating of the positioning.
To Next Page
