2 CPU MODULE INSTRUCTION
2.2 Basic instruction
â– Converting 16-bit/32-bit binary data to Gray code
â– Converting Gray code to 16-bit/32-bit binary data
â– Converting decimal ASCII to 16-bit/32-bit binary data
â– Converting ASCII to HEX
Instruction symbol Description Reference
GRY Page 266
GRYP
GRY_U
GRYP_U
DGRY Page 267
DGRYP
DGRY_U
DGRYP_U
Instruction symbol Description Reference
GBIN Page 268
GBINP
GBIN_U
GBINP_U
DGBIN Page 269
DGBINP
DGBIN_U
DGBINP_U
Instruction symbol Description Reference
DABIN Converts a 5-digit decimal ASCII value in the device specified by (s) to a 1 word binary value, and
stores the converted data in the word device number specified by (d).
Page 270
DABINP
DABIN_U
DABINP_U
DDABIN Converts a 10-digit decimal ASCII value in the device specified by (s) to a 2 word binary value, and
stores the converted data in the word device number specified by (d).
Page 272
DDABINP
DDABIN_U
DDABINP_U
Instruction symbol Description Reference
HEXA Converts the ASCII data stored in the number of characters specified by (n) starting from device
specified in (s), and stores the converted data in the device specified by (d) onwards.
Page 274
HEXAP
(s) (d)
BIN (-32768 to 32767)
Conversion to gray code
(s) (d)
BIN (0 to 65535)
Conversion to gray code
(s+1, s) (d+1, d)
BIN (-2147483648 to 2147483647)
Conversion to gray code
(s+1, s) (d+1, d)
BIN (0 to 4294967295)
Conversion to gray code
(s) (d)
Gray code (-32768 to +32767)
Conversion to binary data
(s) (d)
Gray code (0 to 65535)
Conversion to binary data
(s+1, s) (d+1, d)
Gray code (-2147483648 to +2147483647)
Conversion to binary data
(s+1, s) (d+1, d)
Gray code (0 to 4294967295)
Conversion to binary data
