598
7 APPLICATION INSTRUCTION
7.19 Clock instruction
• Three devices are occupied by (s4) and (d). Make sure that these devices are not used by other machine controls.
• Specify each operand of the word device after reading the value of the special register used in the TRD(P) instruction when
the time (hour, minute, second) of the clock data of the built-in real time clock in the CPU module is used.
Error code
(SD0/SD8067)
Description
2820 The device range specified exceeds the corresponding device range.
3405 The value specified by (s1) and (s4) is outside the following range.
0 to 23
The value specified by (s2), (s3), (s4)+1, and (s4)+2 is outside the following range.
0 to 59
To Next Page
