7 APPLICATION INSTRUCTION
7.21 Module access instruction
617
7
â– TOD(P)
• These instructions write the (n) points of data in the device starting from the one specified by (s2) to the buffer memory
address specified by (s1) in intelligent function module specified by (U/H).
• When a constant is specified in (s2), (n) words of the same data (the value specified by (s2)) is written starting from the
specified buffer memory address.
(s2) (s1)
CPU module Buffer memory
(n) points
(n) words
(s2)
(s1)
0
5
5
5
5
CPU module Buffer memory
(n) words (The same data is written.)
