9 HIGH-SPEED COUNTER INSTRUCTION
9.1 High-speed Processing Instruction
641
9
Function number 10
The measuring start and stop of the pulse density (rotation speed measurement) can be controlled for each channel of the
high-speed counter.
Function number 30
For the multi-output high-speed comparison table, specification of a channel is not required. To start the multi-output high-
speed comparison table, set 01H in (s2). To stop it, set 01H in (s3).
Function numbers 40 and 50
The measuring start and stop of pulse width measurement and PWM can be controlled for each channel.
• When values that turn on the same channel are set for start and stop, the stop operation is prioritized.
• To start the multi-output high-speed comparison table (function number: 30), the high-speed counter must be started using
the HIOEN instruction in advance.
• The high-speed input/output instructions operate according to the following parameters.
Bit position
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
Bit position
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
Valid
Bit position
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
CH4 CH3 CH2 CH1
Function
number
Function specified by the HIOEN instruction Parameter setting
0 High-speed counter Channel setting of the high-speed counter
10 Pulse density (rotation speed measurement) Channel setting of the pulse density/rotation speed measurement
High-speed counter
30 Multi-output high-speed comparison table Output setting of the high-speed counter
40 Pulse width measurement Channel setting of the pulse width measurement
50 PWM Channel setting of PWM
Error code
(SD0/SD8067)
Description
1810 A channel number which is used in another instruction is specified.
3405 An invalid function number is specified in (s).
3600 A channel number which is not selected in the parameter setting is executed.
