13 MODBUS COMMUNICATION INSTRUCTION

13.1 MODBUS Read/Write

683

Operation error

For communication errors, refer to  MODBUS communication manual.

Error code

(SD0/SD8067)

Description

1810 Channel used by the instruction is used by other instruction.

3600 Invalid parameter setup.

2822 Device that cannot be used by this instruction is specified.

3405 Data outside the allowable range was input.

2820 The specified device exceeds the range of the corresponding device.
