688
14 DIVIDED DATA READ/WRITE FROM/TO BFM INSTRUCTION
14.2 Divided BFM write
â– Related devices
• Do not stop the instruction while it is being executed. If driving is stopped, the buffer memory write processing is
suspended, but the data that is already written is stored in (m2) onwards.
• When indexing is executed, the contents of index registers at the beginning of execution are used. Even if the contents of
index registers are changed after the instruction, such changes do not affect the process of the instruction.
• Do not update (change) the contents of (n1) points starting from (s2) while this instruction is executed. If the contents are
updated, the intended data may not be written to the buffer memory areas.
• This instruction cannot be used in FX5 series intelligent function modules.
• This instruction cannot be used while a interrupt routine program is being executed.
Device Name Description
SM8029 Instruction execution complete Turns ON when an instruction is finished normally.
SM8328 Instruction non-execution Turns ON when the RBFM instruction or WBFM instruction in another step is executed for
the same module number.
SM8329 Instruction execution abnormal end Turns ON when an instruction is finished abnormally.
Error code
(SD0/SD8067)
Description
2441 Communication procedure with module is not completed correctly when this instruction is executed.
2801 Module with the module number specified by (U/H) does not exist or the specified module is not an FX series module.
2823 The number of transfer points specified by (n1) and the buffer memory number specified by (s1) is beyond the buffer memory range.
2820 The number of transfer points specified by (n1) and the device number specified by (s2) is beyond the specified device range.
3580 Instructions that cannot be used in an interrupt routine program are being used.
To Next Page
