Controls/Features

MixMode

Inthismode50%oftheairowisdirectedtothedefrostandsidede-mistairoutletsand50%of

theairowisdirectedtotheoorairoutlets,whilefresh(outside)airiscirculatedinsidethevehicle.

TheA/Ccompressorturnsonandoffautomaticallyasneededwheninthismodetoreduce

humiditylevelsandhelpreducemoisturebuilduponthewindshield.

Defrost

Inthismodealloftheairowisdirectedtothedefrostandsidede-mistairoutlets,andfresh

(outside)airiscirculatedinsidethevehicle.

TheA/Ccompressorturnsonandoffautomaticallyasneededwheninthismodetoreduce

humiditylevelsandhelpreducemoisturebuilduponthewindshield.

Toremovestaleairorsmokewhileairconditionerisoperating,youmaywanttoopenaventwindowforashortperiodoftime.Alwaysparkin

theshadewhenpossible.Ifyourvehiclehasbeenparkedinthesunwiththewindowsup,removetheoverheatedairinsidebydrivingwith

windowsdownandtheairconditionerONforoneortwocityblocks.
