Operation

IndicatorsaboutLowDEFlevel(ForVehiclesEquippedwithCummins

ISX15Engines)(cont.)

LevelIndicationAudibleAlarmLCDTextMessage

VehicleConditions

/Operation

(Flashing)

(Solid)

1Beep

ScrollsbetweenSEE

VISORFORINFO,DEF

LOWENGDERATED

40%,andWARN

ENGINE.

Engineperformanceis

LIMITED.DEFlevelis

0%.

(Flashing)

(Solid)

1Beep

ScrollsbetweenSEE

VISORFORINFO,DEF

LOWENGDERATED

5MPH,WARNENGINE,

andSTOPENGINE.

Vehiclespeedislimited

to5mph(8km/h).

170
