Operation

IndicatorsaboutLowDEFlevel(ForVehiclesEquippedwithCummins

ISX15Engines)

LevelIndicationAudibleAlarmLCDTextMessage

VehicleConditions

/Operation

(Solid)

1Beep

ScrollsbetweenSEE

VISORFORINFOand

DEFLOWREFILL

SOON.

InitialWarning–normal

engineoperation.DEF

levelis10%orlower.

(Flashing)

1Beep

ScrollsbetweenSEE

VISORFORINFOand

DEFLOWREFILL

SOON.

InitialWarning–normal

engineoperation.DEF

levelis5%orlower.

(Flashing)

(Solid)

1Beep

ScrollsbetweenSEE

VISORFORINFO,DEF

LOWENGDERATED

25%,andWARN

ENGINE.

Engineperformanceis

LIMITED.DEFlevelis

2.5%orlower.

169
