Operation

NOTE:Thefollowingtableisatypicalrepresentationof2010

DPFemissionsprocedures.

DieselParticulateFilter(DPF)RegenerationTable

LevelEngineOptionIndication

Audible

Alarm

LCDText

Message

Vehicle

Conditions

/Operation

ActionRequired

1All

(Solid)

None

Scrolls

between

SEE

VISOR

FOR

INFOand

PARKED

REGEN

REQUIRED.

Exhaustlter

regeneration

required.

Driveonhighwayathighwayspeedsor

startParkedRegenerationtopreventlossof

power.

2All

(Flashing)

None

Scrolls

between

SEE

VISOR

FOR

INFOand

PARKED

REGEN

REQUIRED.

Exhaustlter

isfull.

WARNING

Failuretoobservethe

followingwarningmaycause

propertydamage,personal

injury,ordeath.

Pullvehiclesafelyoffroadwayandstart

ParkedRegenerationtopreventlossof

enginepower.

179
