MaintenanceIntervalsandSpecications

1.Under-HoodPowerDistributionModule(PDM)

IfyoucannotndthePDMinthislocation,itmeansthatyour

vehiclehasin-linefusesinsteadofaPDMfusepanel.

Thefollowingillustrationshowsthetypicallayoutofthefuse

panelintheunder-hoodPDM.

CAUTION

Topreventelectricalcomponentdamage,when

replacingafuse,alwaysuseonewiththesame

amprating.

270
