Controls/Features
Quadrant1–DisplayMessagesDescription
DieselParticulateFilterLevelTheinstrumentpanelgaugeclustershalldisplaytherelativeDieselParticulateFilter(DPF)Level.
Theinstrumentpanelgaugeclusterdisplaysthefollowinggraphic:
WithL(low)ontheleftandH(high)ontheright,thegraphisshownbybarseachrepresentinga10%
increase/decreaseinsootlevel.
Theinstrumentpanelgaugeclusterdisplaysthelastreceivedleveluntilanewvalueisreceived,oruntil
theinstrumentpanelgaugeclusterdetectsthatithasnotreceivedaresponsetotheSPNrequest,in
whichcaseitshalldisplaytheworddatan/awithinthebargraph.
71
