Navistar ProStar+ User Manual

Controls/Features
WarningMessages
InadditiontotheDiagnosticTroubleCodes(DTC),thedigital
displaywilldisplayawarningmessagewheneverafaultindicator
isilluminated.Thiswarningmessagewillbetoggledwiththe
normalDTCasfollows:
AMBERWarningLamp:FAULTMESSAGE
REDStopLamp:StopEnginemessage
Thefollowingchartprovidesthewarningmessagesthatare
displayedalongwithcorrespondinginstrumentpanelgauge
clusterindicators.
WarningIndicatorWarningMessage
RedStopLampStopEngine
AmberWarningLampWarnEngine
Quadrant3:DisplayMessages
OutsideTemperatureandCompassDisplays(Optional)
TheoptionalOutsideT emperatureandCompassHeadingis
displayedinQuadrant3.TypicaldisplaysforT emperatureand
CompassHeadingarelistedinthefollowingtable.Thedisplay
providesboththeoutsideambienttemperatureandtherelative
directionofthevehiclewithinaparticulargeographicalzone.
Vehiclemustbemovingtoacquireanaccuratetemperature.
Quadrant3–
DisplayMessages
Description
Outside
Temperatureand
CompassHeading
DisplayFormat:
OutsideTemperatureReading
TheOutsideTemperatureisdisplayedontherstlineof
Quadrant3abovetheCompassHeading.Thetemperature
sensorislocatednearthefrontbumper.Duetoitslocation,
thesensorreadingscanbeaffectedbyroadorengineheat
duringidlingorprevailingdrivingconditions(extendedslow
movement).
Thedisplaywillbein°For°C,dependingontheunitsselected
whileintheodometermode.
