Nordson Asymtek X-1000 Series User Manual

Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-44 P/N 196515 (Revision A)
Diagram Sheet 2-5-5
Conveyor Belt Moves
FmNT Command
y A program command is issued to the
FmNT software.
Controller Area Network (CAN)
y Communications network between
Computer (FmNT) and Conveyor
Controller Module
Conveyor Interface PWA
y Performs conveyor logical functions
such as belt movement (direction,
duration and speed), width adjustment,
operation of pneumatic solenoid valves
for clamps/lift tables, stop pins,
operation of heaters, and SMEMA
communication.
y Receives execution commands and
system setup parameters from FmNT.
Sends conveyor states and status to
FmNT.
Conveyor Stepper Motors
y Two motors drive the Conveyor belts to
move the workpiece through the
dispensing system.
y One motor drives the rear Conveyor
Rail to adjust width between rails.
Conveyor Interconnect PWA
y Passively routes signals between
conveyor controller and individual
conveyor components (sensors,
solenoids, motors).
Pneumatic Solenoids
y Signals from Conveyor Controller open
or close pneumatic solenoid valves,
which operate stop pins, lift tables or
clamp bars, and activate the vacuum
generators for the Purge Station.
Board Sensors
y Detects presence of work pieces in pre-
dispense, dispense, and post-dispense
locations. Signals are routed to
Conveyor Controller via Conveyor
Interconnect PWA.
Motor Cables
Conveyor/Heater
Controller
