Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-126 P/N 196515 (Revision A)
Exercise Sheet 2-14-1
Electrically Testing Part Heaters and Needle Heaters
1. In the FmNT Main Window, click on Tools.
2. In the Tools Window, click on Terminal.
3. Click on Heaters.
4. In the Heater Control Window, locate the loops (channels) for the Heater
Tooling installed on your system
(See Diagram Sheet 2-14-3 on page 2-127).
5. Verify the icons in the On/Off column indicate that each heating tool is OFF
(gray). If any of the tools are ON, double click on the yellow and red icon next
to the loop name to turn them OFF. Wait until the tools are cool (35 °C or less)
as indicated by the value in the PV (present value) column.
6. Turn off power to the dispensing system by pressing OFF (0) on the Operator’s
Console and switch the Main Circuit Breaker OFF (0). Lock out and tag out the
power as specified in the Safety section of this manual.
7. Open the Hatch and disconnect the electrical cable to each Heater Module.
8. With a multimeter, measure and record resistance between connector pins 1
and 2 for each Heater Module.
 The resistance for a Heater with one heating element should be 60 ohms.
 The resistance for a Heater with two heating elements should be 30 ohms.
 If the Heater Tooling does not meet the resistance requirements, it should
be repaired or replaced before proceeding.
9. Reconnect the electrical cables, and close the Hatch.
10. Restore power to the dispensing system by turning the red EMO knob
counterclockwise
Make sure the Heater Tooling is cool before performing this
procedure or serious injury may occur.
