Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-147 P/N 196515 (Revision A)
Exercise Sheet 2-16-1
Checking Stop Pin, Lift Table and Clamp Bar Operation
Checking Stop Pin Operation:
This procedure assumes that the dispensing system Hatch is open and FmNT is on the
Station I/O Diagnostic tab of the MPC555 I/O Diagnostic dialog box.
1. In the Station I/O Diagnostic dialog box, locate the
Stop Pin output buttons
(See Diagram Sheet 2-8-1 on page 2-69).
2. Raise the Stop Pin in the pre-dispense station by clicking on the
Stop Pin
button in the Preheat Station area of the dialog box.
3. Lower the Stop Pin by clicking again on the
Stop Pin button.
4. Repeat Steps 2 and 3 for the dispense station and the post-dispense station.
 The Stop Pins should raise and lower smoothly.
 If the Stop Pins do not operate as specified, refer to Lesson 4-8
“Troubleshooting Conveyor” on page 4-97 of this manual.
Checking Lift Table and Clamp Bar Operation:
The pneumatic lines used in configurations with Lift Tables activate the clamp bars in
other configurations. This procedure assumes that the dispensing system hatch is
open and FmNT is on the Station I/O Diagnostic tab of the MPC555 I/O Diagnostic
dialog box.
1. Check under and around all Lift Tables, Clamp Bars, and Heater Tooling to make
sure that no electrical or pneumatic lines are in danger of being pinched or
snagged.
2. Make sure that no electrical or pneumatic lines are touching the Scale or Scale
Base.
3. Manually place production sample workpieces on the Conveyor in the pre-
dispense, dispense, and post-dispense stations.
4.
In the Station I/O Diagnostic dialog box, locate the Clamp/Lifter output
buttons
(See Diagram Sheet 2-8-1 on page 2-69).
5. Raise the Lift Table/Clamp Bars in the pre-dispense station by clicking on the
Clamp/Lifter button in the Preheat Station area of the dialog box.
6. Lower the Lift Table/Clamp Bars by clicking on the
Clamp/Lifter button.
7. Repeat Steps 4 to 6 for the dispense station and the post-dispense station.
 The Lift Tables or Clamp Bars should raise and lower smoothly and no parts
should shift during the lifting and lowering process.
 If the Lift Tables or Clamp Bars do not operate as specified, the air pressure
may need to be adjusted as specified in the in
Exercise Sheet 2-4-2 on page
2-34 and Exercise Sheet 2-16-3 on page 2-150.
 If air adjustment does not remedy the problem, refer to Lesson 4-8
“Troubleshooting Conveyor” on page 4-97 of this manual.
