Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 3-20 P/N 196515 (Revision A)
Exercise Sheet 3-4-1
Draining the Water Trap
Tools and Materials Needed:
 Container for waste water
1. Perform a Service Shutdown as described in Information Sheet 1-3-2 on page
1-11.
2. Locate the water trap at the rear of the system.
3. Hold a container under the water trap to catch the water.
4. Open the water drain knob by turning counterclockwise.
Make sure that all air pressure to the system has been
removed before opening the drain or serious injury may
occur.
5. After the trap has been drained, close the water trap drain knob by turning
clockwise.
6. Perform a Post-Service Startup as described in Information Sheet 1-3-4 on page
1-14.
Safety Precautions:
1. Do not remove the bowl guard protecting the water trap.
The bowl is made of polycarbonate plastic, which could rupture from over-
pressurization.
The bowl could also rupture if it has been exposed to chemicals incompatible
with polycarbonate.
2. Removing the bowl guard could cause serious bodily injury.
