Nordson Asymtek X-1000 Series - Computer Power Supply; Conveyor Controller

Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-23 P/N 196515 (Revision A)
Information Sheet 2-3-2
Power Distribution (Continued)
D. Computer Power Supply
1. The Computer Power Supply receives power directly from the Power
Manager.
2. It distributes power to:
Main Interface PWA (+5,-5, 12,-12 VDC)
Main CPU Board (5, 12 VDC)
PMAC Card (+5, -5,-12,+12 VDC)
PIO – 96 IO Card (5 VDC)
ITI Vision
E. Conveyor Controller
1. The Conveyor Controller receives power directly from the Power Manager.
2. It distributes power to:
Conveyor Motor
Conveyor Sensor
Heater Blocks/Needle Heater (208-240 VAC)
Refer to 1720-00BD, Sheet 3.
