Nordson Asymtek X-1000 Series User Manual

Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-72 P/N 196515 (Revision A)
Exercise Sheet 2-8-4
Leveling the Conveyor
1. In the FmNT Main Window, click on the Configuration button and select Setup
Height Sensor.
2. In the Height Sensor Configuration dialog box, click on CAN-HS
(See Diagram
Sheet 2-11-1 on page 2-95).
3. In the second Height Sensor Configuration dialog box, click on the ARM/DISARM
button.
4. Click on the ARM/DISARM button until the “Current Arm State” reads ARMED.
 The Height Sensor Probe should be in the down position.
5. Click on OK twice to return to the Main Window.
6. In the Main Window, click on the Jog icon
.
7. In the Jog Commands dialog box, click on Dispenser.
8. Using the target box or position controls, move the Height Sensor Probe over the
left front Conveyor Rail.
 Avoid contacting Board Sensors or other components attached to the rail.
9. Using the position controls, lower the Dispensing Head toward the rail until the
green LED on the Height Sensor goes ON.
10. Raise the Dispensing Head with the Z-axis slow jog button
until the green LED
goes OFF.
11. Lower the Dispensing Head with the Z-axis slow jog button
just until the green
LED illuminates (one click past the LED being OFF).
12. Record the Z-axis reading displayed in the Jog Commands dialog box in the area
just below the target box.
13. Raise the Dispensing Head and, using only Y-axis position controls, move the Height
Sensor Probe over the left end of the rear rail.
 A slight X-axis movement may be needed to avoid obstacles.
14. Repeat Steps 8 to 13 at the center and far right end of the rails
(See Diagram Sheet
2-8-2 on page 2-73 for approximate locations).
15. Calculate the variance in rail height from end to end and between front and back
rails.
 The height variance of each rail from one end to the other should be within
±0.005 inch (±0.127 mm).
 The height variance between front and back rails at the measured locations
should be within ±0.005 inch (±0.127 mm).
 If the rail is determined to be out of level, call Asymtek Technical Support.
Only trained service technicians should attempt to adjust the level
of the Conveyor Rails.
