Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 5-10 P/N 196515 (Revision A)
Exercise Sheet 5-3-1
Removing a Pneumatic Solenoid Valve
Tools and Materials Needed:
• Phillips Head Screwdriver • 4-way Replacement Valve
• 4-mm Hex Key • Two P/N 01-0306-00 Conveyor O-Rings
Part Number Valve
197396 4-way Replacement Valve
197397 Dual 3-way Replacement Valve
All components and fasteners removed during this procedure should be
retained in an orderly manner and in a safe location for reinstallation or
shipment back to Asymtek.
1. Perform a Service Shutdown as specified in the Safety section of this manual.
2. Remove the 4-mm socket head cap screws attaching the Access Hatch Cover to the
back of the dispensing system.
3. Turn the Phillips head clamp screw of the damaged PSV ten complete turns
counterclockwise.
This will loosen but not remove the clamp screw.
4. While pressing down gently on the clamp screw head, lift up on the front end of the
PSV, and then unhook the rear end of the Valve from the rear clamp bracket.
Pressing on the head of the clamp screw opens the front and rear clamp
brackets.
5. Remove the damaged PSV.
This procedure should only be performed by a trained service technician.
Foreign matter on sealing surfaces of the Solenoid Valve will result in air
leakage. Make sure that these surfaces remain clean during the
performance of this procedure.
