Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-154 P/N 196515 (Revision A)
Information Sheet 2-17-1
PMAC
A. PMAC Initialization Files
1. There are several FmNT files that contain configuration variables for the
PMAC.
2. These files are downloaded to the PMAC upon FmNT startup and include the
following:
PMACINI.PMC
- This file contains several servo parameters and PMAC configuration
variables.
- The variables are similar to personality parameters and contain
information such as travel limits, speeds, accelerations, and
motor/encoder resolutions.
FMCONFIG.INI
- This file contains needle/camera offsets, purge preferences, and valve/
accessory information.
- If the FMCONFIG.INI is not setup correctly, the software will use
incorrect tuning parameters, which could lead to a following error.
 A following error is the difference between the Calculated Position
and the Actual Position, at any given point in time.
 A fatal following error is the maximum distance the positioner may
lag (or lead) before the system shuts down for safety reasons.
PMAC.XML
- The PMAC has a list of tuning parameters for different weight classes,
which may be configured/mounted to the Z head.
SNXXXXX.PMC
- This is the calibration map, specific to the mechanics of the given X-
1000.
