Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 3-42 P/N 196515 (Revision A)
Exercise Sheet 3-8-1
Disconnecting the DP-3000
Tools Needed:
 5/64-inch hex key
1. Disconnect the DP-3000 black pneumatic hose from the manifold.
2. Disconnect the DP-3000 blue pneumatic hose from the manifold.
3. Disconnect the syringe receiver head hose from the manifold.
4. Disconnect the DP-3000 power cable from the dispense head.
5. Remove the DP-3000 from the dispensing system.
6. For the quick-release bracket, rotate the orange locking lever up 180° and slide
the pump up and out of the dovetail receiver assembly.
7. For the standard bracket, use the 5/64-inch hex key to loosen the setscrews on
the right side of the valve bracket, and then slide the pump out of the valve
bracket.
8. Unscrew the syringe or fluid cartridge from the Luer adapter and remove the
syringe or fluid cartridge.
9. Remove and save the syringe receiver head. Discard the syringe according to
the material disposal guidelines in the Material Safety Data Sheet.
10. Open the swinging bracket by lifting up on the (red) bracket latch.
11. Flip the stopcock lever (yellow) forward to release the stopcock.
12. Flip the chamber retention lever (green) up 90° so that it is horizontal.
13. Press down on the sliding bracket, and slide the carriage down.
14. The blue detent lever should lock the carriage securely in the down position.
15. Remove and discard the dispensing needle, Luer adapter and stopcock.
16. Slide the chamber retention slide from left to right, releasing the pumping
chamber.
17. Retracting the piston will make chamber removal easier. You can use the upper
knob to retract the piston.
18. Pull down on the pumping chamber and remove it from the chamber retention
bracket.
