Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-70 P/N 196515 (Revision A)
Exercise Sheet 2-8-2
Checking Adjustable-Width Conveyor Clearance
Perform this procedure only if your dispensing system has been
configured for an application that requires an adjustable conveyor width.
DO NOT perform the procedure for fixed-width conveyor configurations
.
1. Verify that electrical cables and pneumatic lines near the conveyor are not in
danger of being pinched or snagged during conveyor operation.
2. In the FmNT Tools Window, click on the Jog icon
.
3. In the Jog Commands dialog box, click on Conveyor.
4. Click on Home in the Jog Commands dialog box and make sure that the rear
conveyor rail moves to the home position at the rear of the dispensing system.
The rear conveyor rail should start moving to the rear of the dispensing
system.
Rear conveyor rail movement should be smooth and not damage any
electrical lines or pneumatic hoses.
5. While the conveyor rail is moving, lift the hatch.
The green beacon light should go OFF, the yellow beacon light should come
ON, and the conveyor rail should stop moving.
6. Close the hatch.
The yellow beacon light should go OFF, the green beacon light should come
ON, and the conveyor rail should continue moving to the Home position.
7. In the Jog Commands dialog box, click on both the slow
and the fast
X-axis jog buttons to move the conveyor belt in both directions.
The conveyor belt should move smoothly with no slipping on its pulleys.
8. In the Jog Commands dialog box, click on both the slow
and the fast
Y-axis jog buttons to move the conveyor belt backward and forward.
The conveyor rail should move smoothly in both directions.
9. Close the Jog Commands dialog box to return to the Tools Window.
10. In the Tools Window, click on the Return to Main Window icon
.
