Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-52 P/N 196515 (Revision A)
Exercise Sheet 2-6-2
Calibrating the Camera
1. In FmNT Main Window, click on Configuration.
2. Select Setup Vision from the Configuration menu.
The Dialog Window for the Vision System opens
(See Diagram Sheet 2-6-3
on page 2-53).
3. In the Dialog Window, click on the Calibrate button.
A video window is displayed that includes the video screen, light controls,
and position controls. Prompts are displayed at the top of the window that
lead the user through a series of steps to calibrate the camera.
4. The first window prompts the user to load a sample production workpiece that
contains a model fiducial. Click on Next to load the workpiece.
5. The second window asks the user to select a model fiducial on the sample
workpiece. Use the video position controls to move the camera over the fiducial.
When the fiducial has been selected, click on Next.
6. The third window asks if the model fiducial is acceptable. If so, click on Next.
The dispensing head will start moving.
7. At the top of the fourth window, a series of measurements in the X- and Y-axes
and a confidence level are displayed.
The confidence level should be 90 percent and higher. If it is not, contact
Asymtek Technical Support.
At the end of the measurement routine, the actual dimensions of a single
pixel will be given in the X and Y-axes.
8. Click the Done button to return to the Vision Parameters dialog box.
9. Click on OK to return to the FmNT Main Window.
