Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 4-30 P/N 196515 (Revision A)
Information Sheet 4-3-1
Testing the I/O Functions of the Dispenser and Conveyor
A. Testing I/O Functions
1. The TS-03 test kit is a device used to test the internal and external
communications (I/O) of the system modules.
It contains a TS-01 test box and TS-03 cables (See Diagram Sheet 4-3-2
on page 4-35).
The box is connected to the system module and is used to verify the
integrity of the I/O bits.
2. The TS-01 Interface Simulator is a small Asymtek device used to simulate
conveyor communication between the dispensing system and neighboring
material handling conveyors.
B. Conveyor I/O Test
1. The Conveyor I/O Test window gives the current state (ON or OFF) of all of
the Conveyor Inputs and Outputs and Auxiliary Inputs and Outputs.
2. This window can be accessed, and these functions performed, from either
the I/O Test on the Setup Conveyor option on the Configuration Menu, or
from the I/O Test button in the Tools Window.
3. Dispensing systems equipped with dual-lane conveyors will have two
conveyor buttons in the I/O test window, one for each conveyor.
4. The Outputs can be turned ON (1) or OFF (0) in this window by clicking on
the ON/OFF button next to the I/O.
5. Test the responsiveness of each Output by turning it ON and OFF, checking
the machine to make sure that it is responding.
6. This dialog box may also include a Control tab containing Position Controls
for moving the conveyor belt and rail.
