Page #208 background image
Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-150 P/N 196515 (Revision A)
Exercise Sheet 2-16-3
Adjusting the Lift Table/Clamp Bar Airflow
1. Open the dispensing system Hatch.
Do not reach into the dispensing chamber until yellow beacon light is
displayed and all system motion has stopped. If the Heaters are hot,
use extreme caution when performing this operation.
2. Locate the Flow Control Valves (FCVs) for the appropriate Lift Table or Clamp
Bar
(See Diagram Sheet 2-16-2 on page 2-151).
 To gain access to the FCVs, it may be necessary to remove the Dispensing
Area Front Cover as shown in
Diagram Sheet 2-16-3 on page 2-152.
3. Adjust the FCVs as follows:
 For Lift Tables, adjust FCV with the black hose for upward speed, and FCV
with the blue hose for downward speed.
 For Clamp Bars, use a flat bladed screwdriver to turn the recessed FCV
adjustment screws as necessary to synchronize the Clamps.
4. Repeat the operational check and adjustment procedures as necessary to obtain
the desired results.
5. Once you are satisfied with the operation of Clamp Bars or Lift Tables, click on
OK and then in the next dialog box, click on OK to return to the Main Window.
6. If it was removed, replace the Dispensing Area Front Cover and then close the
dispensing system Hatch.
