Nordson Asymtek X-1000 Series User Manual

Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-82 P/N 196515 (Revision A)
Exercise Sheet 2-9-2
Dispensing Calibration Module Leveling and Height Adjustment (Continued)
9. Move the camera over the purge station lid. The video image should be clear
and focused.
If the image is not focused, repeat Steps 8 and 9.
If the image is focused and the bubble in the level is in the center of the
circle, go to Step 10.
10. Move the camera back over sample workpiece fiducial, then over the corner
of the ceramic tile, and then over the purge station lid and verify that each
location is still in focus.
If any of the three images is not focused, repeat Step 6 to 10.
If the image is focused and the bubble in the level is in the center of the
circle, the positioning of the DSA is complete.
11. Reinstall the Dispensing Area Front Cover.
