Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-142 P/N 196515 (Revision A)
Exercise Sheet 2-15-5
Adjusting the Downward-facing Board Sensors (Continued)
12. Slide the mode selection switch to Run.
The Amplifier will display the incident light level.
13. Slide the switch to Mode.
14. Dial the thumbwheel until the flashing cursor is next to Output 2 and then
push down on the thumbwheel.
15. Dial the thumbwheel until L (light on) is displayed and then push down on the
thumbwheel to select.
16. Dial the thumbwheel until non is displayed and then push down on the
thumbwheel to select.
17. Dial the thumbwheel until FR1 (Frequency 1) is displayed and then push down
on the thumbwheel to select.
18. To program Output 2, slide the mode selection switch to Set.
19. Load a sample workpiece onto the conveyor and slide it over/under the optic
sensor.
20. Push down on the thumbwheel to set the ON condition for Output 2.
“2nd” will display after a moment.
21. Move the sample workpiece out from under/over the optic sensor.
22. Push down on the thumbwheel to set the OFF condition for Output 2.
GOOD should display for 2 seconds, indicating the ON-OFF threshold is
identifiable. If HARD is displayed, then the sensor may not be able to tell
the difference between ON and OFF. The sensor lens will require realignment
before proceeding.
23. While the programmed level for Output 2 is displayed, adjust the value up to
1000 by toggling the mode selection switch until 1000 is displayed.
This makes sure that Output 2 never turns ON.
24. Slide the mode selection switch to Run.
To Next Page
