Nordson Asymtek X-1000 Series User Manual

Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 3-3 P/N 196515 (Revision A)
Information Sheet 3-1-2
Routine Maintenance Procedure Schedule (Continued)
Maintenance
Procedure
Recommended
Frequency
Est.
Time
Instructions
Lubricate the X-
and Y-Axis
bearings.
Monthly
30
minutes
See Exercise Sheet 3-5-1 on page 3-24.
Clean Board
Sensors.
Monthly
30
minutes
Use a clean, soft cloth to wipe any dust off of the
sensors.
• Clean, dry pressurized air may be used if
your application does not use thermal
grease.
• Depending on your system configuration,
there may be as many as three Board
Sensors present.
Lubricate the
Mechanical Cables.
Quarterly
30
minutes
See Exercise Sheet 3-6-1 on page 3-28.
Replace Conveyor
Belts.
Semi-annually
30
minutes
See Exercise Sheet 3-7-1 on page 3-35 and
Exercise Sheet 3-7-2 on page 3-36.
Calibrate the Scale. Semi-annually
20
minutes
See Exercise Sheet 3-3-3 on page 3-16.
