Nordson Asymtek X-1000 Series - Page 271

Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 3-45 P/N 196515 (Revision A)
Diagram Sheet 3-8-2
DP-3000 Chamber Assembly
Black O-Ring
Urethane O-Ring
Priming Chamber
Metal Lue
r
Prime Por
t
Pumping Chamber Sea
l
(insert ring-side down)
Pumping Chambe
r
Priming O-Ring
Priming Chamber
Static O-Ring
Pumping Chambe
r
Seal (insert ring
-
side down)
Pumping Chambe
r
Plastic Prime Por
t
Standard Chamber Assembly
High Pressure Chamber Assembly
