Nordson Asymtek X-1000 Series User Manual

Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 4-104 P/N 196515 (Revision A)
Exit FmNT, shut down
Windows NT and press the
black
OFF (0) button on the
Operator’s Console
Switch Main Circuit Breaker
to
OFF (0) position, and
disconnect Power Cable from
the facility outlet
Check continuity of Conveyor
Signals Cable
(Pinout is 1 to 1).
Is there continuity?
Conveyor Controller
(P/N 62-1677-00 for
X1020 or 62-1676-00 for
X1010) has failed.
Conveyor Signals Cable
(P/N 06-4610-00) has
failed
Yes No
Exit FmNT, shut down
Windows NT and press the
black
OFF (0) button on the
Operator’s Console
Switch Main Circuit Breaker
to
OFF (0) position, and
disconnect Power Cable from
the facility outlet
Check continuity of Conveyor
Signals Cable
(Pinout is 1 to 1).
Is there continuity?Is there continuity?
Conveyor Controller
(P/N 62-1677-00 for
X1020 or 62-1676-00 for
X1010) has failed.
Conveyor Signals Cable
(P/N 06-4610-00) has
failed
Yes No
Diagram Sheet 4-8-5
Board Sensor Fault Isolation Procedure - Conveyor Signals Cable Verification Procedure

Nordson Asymtek X-1000 Series Specifications

General

Brand	Nordson
Model	Asymtek X-1000 Series
Category	Dispenser
Language	English
