Nordson Asymtek X-1000 Series User Manual

Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 4-109 P/N 196515 (Revision A)
• Look for damaged electrical cables
• Look for disconnected or poorly secured electrical cables.
Perform the following inspections:
Is mechanical
correction required as
a result of the above
inspections?
Resolve and go to Heater
Verification
Go to Heater Verification
Yes No
• Look for damaged electrical cables
• Look for disconnected or poorly secured electrical cables.
Perform the following inspections:
• Look for damaged electrical cables
• Look for disconnected or poorly secured electrical cables.
Perform the following inspections:
Is mechanical
correction required as
a result of the above
inspections?
Is mechanical
correction required as
a result of the above
inspections?
Resolve and go to Heater
Verification
Go to Heater Verification
Yes No
Diagram Sheet 4-8-10
Heater Fault Isolation Procedure – Mechanical Verification
