Nordson Asymtek X-1000 Series User Manual

Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 4-156 P/N 196515 (Revision A)
Information Sheet 4-13-11
DJ-2000 Troubleshooting (Continued)
Q. Dots Are Too Flat
Possible Cause Recovery
 Dispenser heater
temperature too high
 Reduce temperature 2°C (3.6°F) at a time. Refer to
Section 4 – Heater Control for Windows (HCW) of the
Fluidmove for Windows Installation and User Guide.
 Micrometer setting is too
high
 Reduce the needle stroke by rotating the micrometer
clockwise.
R. Dots Are Too Tall
Possible Cause Recovery
 Dispenser heater
temperature is too low
 Increase the temperature 2°C (3.6°F) at a time. Refer
to Section 4 – Heater Control for Windows (HCW) of
the Fluidmove for Windows Installation and User
Guide.
 Micrometer setting is too low
 Increase the needle stroke by rotating the micrometer
counterclockwise.
S. Skipping Some Dots
Possible Cause Recovery
 Air has gotten into the pump,
possibly from disassembly.
 Prime the DJ-2000. Refer to the procedure, “To
manually prime the DJ-2000” in DJ-2000 Operations
Manual.
